1700-0167, ANSMANN Powerstation 640Wh, 600W, Vin: 12-30Vdc, 8.3A, max. 100W. Output connections: 2× AC socket, 2× USB-A, 1× USB-A QC, 1× USB-C PD

1700-0167, ANSMANN Powerstation 640Wh, 600W, Vin: 12-30Vdc, 8.3A, max 100W. Output connections: 2× AC socket, 2× USB-A, 1× USB-A QC, 1× USB-C PD. With 2× AC sockets 600 W, car socket 12 V 120 W, 2 DC5521 DC outputs, 1 USB-C Power Delivery 60 W, 2 USB-A, 1 USB-A QC 18 W, connection for cable jumper, connection for expansion module and powerful LED lamp.
TECHnical specifications
Input: DC5521 12.0 V ... 30.0 V | 8.3 A | max. 100.0 W
Output:
USB-A1/-A2: 5V, 2.4A, 12W
USB-A QC: 5V, 3A, 15W
USB-A QC: 9V, 2A, 18W
USB-A QC: 12V, 1.5A, 18W
USB-C PD: 5V, 3A, 15W
USB-C PD: 9V, 3A, 18W
USB-C PD: 12V, 3A, 36W
USB-C PD: 15V, 3A, 45W
USB-C PD: 20V, 3A, 60W
DC1/DC2/DC3: 12V, 10A, 120W
AC: 230V 600W
Jump start: 12V 500 A. Clips not included! See 1700-0174, Jump start cable with safety electronics, suitable for ANSMANN Powerstation PS600AC (1700-0167) and PS2200AC (1700-0168)
LED lamp: 10 W LED, 3 dimming levels, SOS and strobe mode
Protective functions: Short-circuit protection Monitoring
temperature Over-voltage protection
Over-current protection
Indication: LED display with percentage indication
Rated voltage: 3.7 V
Energy content: 640 Wh
Cell chemical composition: Lithium iron phosphate
Operating temperature: -20° C ... 55° C
Storage temperature: -20° C ... 55° C
Dimensions: 263 × 221 × 216 mm. Weight: 9.41 kg
Dimensions: Packing + Product: 333 × 375 × 300 mm. Weight: 11.213 Kg.
Equipment:
Powerstation, AC charger, DC 12V connection cable, operating instructions,
warranty certificate
Before using it for the first time, fully charge the Powerstation with
the power supply unit supplied.
Charging possibilities:
- Connecting the supplied power supply to the DC input
- Charging via solar panel
- Charging via 12V car adapter cable
N.B. READ THE GENERAL SAFETY WARNINGS IN THE PRODUCT MANUAL CAREFULLY BEFORE INSTALLATION!
