LDP24-42, LifePo4 25,6V 42Ah battery with EVEREXCEED bluetooth, Term. M8, Dim.260x169xh.215 mm

LDP24-42, LifePo4 25.6V 42Ah battery with EVEREXCEED bluetooth, Term. M8, Dim.260x169xh.215 mm

ELECTRICAL SPECIFICATIONS
Nominal Voltage 25.6 V
Nominal Capacity 30 Ah
Energy 768 Wh
Resistance = <80 mOhm
Self Discharge <1.5% per Month
Series connection 2 Units max.
Parallel connection 4 Units max.

CHARGE SPECIFICATIONS
Recommended Charge Current 15 A
Maximum Charge Current 30 A
Recommended Charge Voltage 28.4 V-29.2 V
BMS Charge Voltage Cut-Off 29.2 V (3.65 ±0.5 vpc) (1.1 ±0.4 s)
Reconnect Voltage 28.8 V (3.6 ±0.05 vpc)
Charging method CC-CV

DISCHARGE SPECIFICATIONS
Maximum Continuous Discharge Current 30 A
Peak Discharge Current 60 A (<2S)
Recommended Low Voltage Disconnect 22 V (2.75 vpc)
BMS Discharge Voltage Cut-Off 16 V (2.0 ±0.08 vpc) (20 ±6 ms)
Reconnect Voltage 20 V (2.5 ±0.05 vpc)
Short Circuit Protection 200-600 µs

TEMPERATURE SPECIFICATIONS
Discharge Temperature: -20°C to 60 °C
Charge Temperature: 0 °C to 50 °C
Recommend Storage Temperature: -5 °C to 35 °C

MECHANICAL SPECIFICATIONS
Dimensions (L x W x H): 328 x 172 x 220 mm
Weight: 7.5 Kg
Terminal Type M6
Case Material ABS
Enclosure Protection: IP55
